Molecular Dynamics Simulation of Radiation Damage and Self Healing Property of Gallium Nitride (GaN)
Envision
Piston
Abstract
Our project presents a classical molecular dynamics study of primary knock on atom (PKA) cascade damage and subsequent recovery through dynamic annealing (self healing) in bulk wurtzite gallium nitride (GaN). A 55,296 atom supercell was equilibrated at 300K using the Tersoff potential with a ZBL hybrid potential for short range correction. A 5 keV Ga PKA was then introduced at the center of the box, and the cascade was evolved through three simulation phases: a ballistic phase with adaptive timestepping, a dynamic recovery phase at 300K, and a quench to approximately 1K for defect counting. Post cascade atomic positions were compared against a perfect 0K reference structure using displacement based defect analysis. Results show that approximately 82% of the cascade induced energy increase recovers within 20ps at 300K, with only 154 atoms remaining displaced by more than 2Å after recovery. These findings confirm the known radiation tolerance of GaN and provide a quantitative basis for understanding its suitability in radiation harsh electronics like space and nuclear environments.
Abstract
Our project presents a classical molecular dynamics study of primary knock on atom (PKA) cascade damage and subsequent recovery through dynamic annealing (self healing) in bulk wurtzite gallium nitride (GaN). A 55,296 atom supercell was equilibrated at 300K using the Tersoff potential with a ZBL hybrid potential for short range correction. A 5 keV Ga PKA was then introduced at the center of the box, and the cascade was evolved through three simulation phases: a ballistic phase with adaptive timestepping, a dynamic recovery phase at 300K, and a quench to approximately 1K for defect counting. Post cascade atomic positions were compared against a perfect 0K reference structure using displacement based defect analysis. Results show that approximately 82% of the cascade induced energy increase recovers within 20ps at 300K, with only 154 atoms remaining displaced by more than 2Å after recovery. These findings confirm the known radiation tolerance of GaN and provide a quantitative basis for understanding its suitability in radiation harsh electronics like space and nuclear environments.
